Name/model

TDW96Y-2000/1422×12200

TDW96Y-3000/1500×12200

Nominal pressure(kn)

20000

30000

Working table lengh(mm)

1650

1900

Working table width(mm)

1800

2000

Max.distance between lower plane of movable cross-beam and upper plane of low cross-beam(mm)

2120

2600

Max.up moving distance of movable cross-beam(mm)

900

900

max.up moving speed of movable cross-beam(mm/s)

60

60

Max.up moving slowly speed of movable cross-beam(mm/s)

7.8

7.8

Pressig speed(mm/s)

1.85

1.85

Quick down speed(mm/s)

102

102
